UCP 1001 A
(2 cylinder)
HYDRAULIC COLD PRESS
PRODUCT INFORMATION DESCRIBED BELOW ↓
HYDRAULIC PRESSURE TO LAMINATION
INDUSTRIAL HEAVY DUTY SOLUTION FOR FURNITURE FACTORY
This machine can be work with multiple types of lamination on composite wood, cork board fibre board, honeycomb board.
CONTROL PANEL
- Having a control panel makes using the machine more comfortable for the user.
- More efficient communication between the user and programming is made possible by the control panel’s display attachment.
PRESSURE PUMP
- A high-powered pressure pump, designed with advanced technology and precision engineering, to provide a consistent and precise transfer of pressure with consistent effectiveness and dependability.
SUSPENSION PISTON
- The equipment is outfitted with a total of 2 high-power hydraulic cylinders, each strategically designed to deliver precise and consistent pressure performance for optimal functionality.
PLATTEN
- The platen is made with MS metal to guarantee durability and longevity, resulting in superior construction quality.
- The planomiller process is utilized on both platens to achieve a smooth finish and eliminate air bubbles when laminating.
RACK & PINION
- Precise steering response: Rack and pinion steering offers direct and responsive control, providing better handling and maneuverability.
- Compact design: The rack and pinion mechanism is more compact than other steering systems, allowing for efficient use of space in the vehicle.
TECHNICAL SPECIFICATION
Buy Hydraulic Coldpress UCP 1001
To enhance your operations, you can now buy the Hydraulic Coldpress UCP 1001 and benefit from its precision and durability. This cold press machine is specially design by UMABOY to function with diverse sorts laminations on composite wood, corkboard, fiberboard, honeycomb board.
- This machine can work with multiple types of lamination on composite wood, corkboard, fiberboard, and honeycomb board.
- Having top-rate capabilities for the furniture and board lamination industry.
- I-beam welded structure for long life.
- Hydraulic cylinder with imported seals.
- Standard accessory for no maintenance
- Hydraulic cylinder with imported seals.
Technical Specifications
| TECHNICAL SPECIFICATION | |
|---|---|
| MODEL | UCP 1001A |
| Pressure board dimensions | 2500 x 1300 mm |
| Max. pressure | 50 tons |
| Max. opening | 1000 mm |
| Power req. | 5 HP |
| Overall dimensions (LxWxH) | 3000 x 1300 x 3050 |
| Cylinder stroke | 1000 mm |
Note: Technical specifications may be changed without any prior notice. Product images are just for the reference.
Explore Our Most Selling Machines
Edge Bander
Panel Saw
Hydraulic Coldpress
Multi Boring
Urex CNC Router
Let's talk !
Please fill out this form and relax.
Our expert executive team will reach out to you and
Offer the most suitable advice according to your needs.
Please contact we would like to help you.
About Hydraulic Coldpress Machine UCP 1001
The Hydraulic Coldpress Machine UCP 1001 feature and advancement
UMABOY’s cold press machine is designed for robust and efficient laminating processes. Here are its key specifications:
Sturdy Body Frame: Constructed with a heavy-duty frame to ensure durability and stability during operation, providing consistent performance under high pressure.
Control Panel: Equipped with an intuitive control panel that allows for precise adjustments and monitoring of the pressing process, enhancing ease of use and operational efficiency.
High-Powered Pressure Pump: Features a powerful pressure pump capable of generating high pressure, essential for effective laminating and ensuring a strong bond between layers.
Heavy Suspension Piston: Includes a robust suspension piston designed to handle significant pressure loads, contributing to the machine’s reliability and effectiveness in laminating.
Strong Platen Frame: The strong platen frame ensures even pressure distribution across the surface, improving the quality and consistency of the laminating process.
These components work together to make UMABOY’s Coldpress Machine highly effective for strong and reliable laminating, suitable for various applications requiring high pressure and durability.
