UMB 63
MULTI BORING MACHINE
PRODUCT INFORMATION DESCRIBED BELOW ↓
ULTIMATE PURPOSE MULTI DRILLING
INDUSTRIAL HEAVY DUTY SOLUTION FOR FURNITURE FACTORY
The triple-head multi-boring machine offers precise and accurate operation. It ensures maximum precision in dowel boring with Umaboy’s high-quality drilling spindles positioned at 32mm intervals, allowing the use of drills with a maximum diameter of 35mm. Perfectly aligned rows of holes and dowel bores are assured.
SIDE BORING HEAD
- To meet the requirements, 21 drilling bits are positioned at a distance of 32 mm
from each other. - Primarily utilized for drilling multiple holes in a long board simultaneously.
- Optimal power and quickness for wood drilling in assembly work
- meticulously crafted to meet the highest standards and comply with all
industry regulations.
SLIDING PANEL
- The sliding panel has been constructed using durable and robust materials to ensure its longevity and reliable performance.
- The sliding panel facilitates smooth movement to the desired location.
- This function ensures the safety and protection of ply by preventing any damage caused by rubbing.
- The design of this sliding panel is to ensure smooth operation even in heavy material.
Bottom Boring Head 1
Bottom Boring Head 2
- 2 bottom heads are equipped. To meet the requirements, 21 drilling bits are positioned at a distance of 32 mm from each other.
- Primarily utilized for drilling multiple holes in a long board simultaneously
- Optimal power and quickness for wood drilling in assembly work
- meticulously crafted to meet the highest standards and comply with all
industry regulations. - Both lower heads can be manually adjusted to move in either direction.
TECHNICAL SPECIFICATION
Multi Boring machine UMB 63A Supplier in India
The triple-head multi-boring machine offers precise and accurate operation. It ensures maximum precision in dowel boring with Umaboy’s high-quality drilling spindles positioned at 32mm intervals, allowing the use of drills with a maximum diameter of 35mm. Perfectly aligned rows of holes and dowel bores are assured. The machine features a solid steel table, sturdy fences, a pneumatic workpiece clamp, and ergonomic operating elements to guarantee top-notch quality. As a premier Multi Boring Machine UMB 63A supplier in India, we provide high-quality, reliable machinery to meet your industrial needs.
Salient Feature
- The machine tool components choose the superior steel materials. they go through the highly and strong heat treatment
- The moving parts choose the high-grade anti-wear materials.
- They are firm and durable.
- The Multi Drill has been meticulously crafted, boasting a multitude of functions that operate at high speeds while maintaining exceptional precision.
- The 3-head multi-boring machine is fitted with one horizontal and two rotating vertical boring heads (0-90°), each equipped with 21 spindles. This machine is specifically designed for efficiently creating holes in a straight line for the side processing of wardrobes
Technical Specifications
| TECHNICAL SPECIFICATION | |
|---|---|
| MODEL | UMB 63 |
| Max. drilling diameter | Max. = 35mm D = 13mm |
| Max. drilling depth | Max. = 60mm |
| Total number of spindles | 21*3 = 63 |
| Installation Dia. of drill bit shaft | 10 mm |
| Max. center dis. between holes | L max. *B max. = 2400*640 mm |
| Min. center dis. between holes | L min. *B min. = 130*32 mm |
| Spindle speed | 2840 rpm |
| Total power | 4.5 kw |
| Overall dimension | 3000*2500*2400 mm |
| Weight air pressure | 0.5 - 0.6 mpa |
Note: Technical specifications may be changed without any prior notice. Product images are just for the reference.
See the UMB 63 in Action
🔧 Watch how the UMB 63 makes an easy process of the boring process:
- Optimal power and quickness
- Designed with 63 drilling bits for ultimate wide production.
- Create precise holes on both surfaces.
🎥 Click to watch the Multi Boring Function Live Demo.
Explore Our Most Selling Machines
Edge Bander
Panel Saw
Hydraulic Coldpress
Multi Boring
Urex CNC Router
Let's talk !
Please fill out this form and relax.
Our expert executive team will reach out to you and
Offer the most suitable advice according to your needs.
Please contact we would like to help you.
About Industrial Multi Boring machine UMB 63A
The Triple-Head Multi-Boring UMB 63A Machine from UMABOY provides exceptional precision and accuracy for dowel boring and drilling. With three heads, each equipped with 21 high-quality drilling spindles set at 32mm intervals, it accommodates drills up to 35mm in diameter, ensuring perfectly aligned rows of holes and dowel bores. The machine features a robust steel table, durable fences, pneumatic workpiece clamps, and ergonomic controls for superior quality and ease of use. As a leading supplier of the UMB 63A in India, we deliver top-notch, reliable machinery to meet your industrial needs.
The Triple Head Multi Boring machine UMB 63A feature and advancement
Features:
- Equipped with Three Heads: The 3-Head multi-boring machine is fitted with one horizontal and two rotating
vertical boring heads (0-90°), each equipped with 21 spindles. This machine is specifically designed for efficiently
creating holes in a straight line for the side processing of wardrobes - Power Performance: The Multi drill has been meticulously crafted, boasting a multitude of functions that operate
at high speeds while maintaining exceptional precision.
Two Bottom Head: - 2 Bottom heads are equipped To meet the requirements, 21 drilling bits are positioned at a distance of 32 mm from each other.
- Primarily utilized for drilling multiple holes in a long board simultaneously
- Optimal power and quickness for wood drilling in assembly work
- meticulously crafted to meet the highest standards and comply with all
industry regulations. - Both lower heads can be manually adjusted to move in either direction.
- Depth Control Ensures consistent hole depths across different materials.
- CNC Integration: Enables programmable drilling patterns for complex tasks.
Sliding Panel: - The sliding panel has been constructed using durable and robust materials to ensure its longevity and reliable performance.
- The sliding panel facilitates smooth movement to the desired location.
